The PENN® Authority is engineered for anglers who demand maximum power, unmatched durability, and elite saltwater performance. Built to be the most advanced spinning reel in the PENN lineup, the Authority delivers industry-leading sealing, ultra-smooth operation, and the strength needed for big-game species in the harshest conditions.
Crafted with a full metal body, sideplate, and rotor, the Authority maintains perfect gear alignment under heavy loads. The IPX8 sealed body and spool design provides complete protection against water intrusion, allowing reliable performance even when fully submerged. Inside, CNC Gear™ Technology, stainless steel main and pinion gears, and sealed stainless steel bearings create incredible torque, smoothness, and longevity.
The Authority’s Dura-Drag™ system offers powerful, consistent drag pressure without hesitation, making it ideal for tuna, stripers, halibut, tarpon, and other hard-fighting species. Whether casting from the surf, jigging offshore, or battling big fish from the boat, the PENN Authority stands at the top of modern spinning reel design.
Key Features
-
Full metal body, rotor, and sideplate for maximum strength
-
IPX8 sealed body and spool – submersion-ready water protection
-
CNC Gear™ Technology with precision stainless steel gearing
-
Dura-Drag™ system delivers smooth, consistent drag performance
-
12+1 sealed stainless steel ball bearings for unmatched smoothness
-
Braid-ready spool with line capacity rings
-
Designed for heavy saltwater applications and big-game species
| MODEL NUMBER | REEL SIZE | GEAR RATIO | RETRIEVE | MAX DRAG | # BALL BEARINGS | MONO CAPACITY (M/MM) | BRAID CAPACITY (M/LB) |
|---|---|---|---|---|---|---|---|
| ATH2500 | 2500 | 5.7:1 | Right/Left | 20lb | 9.1kg | 13 | 235/0.23 160/0.28 130/0.31 | 240/10 220/15 160/20 |
| ATH2500HS | 2500 | 7.0:1 | Right/Left | 20lb | 9.1kg | 13 | 235/0.23 160/0.28 130/0.31 | 240/10 220/15 160/20 |
| ATH3500 | 3500 | 5.7:1 | Right/Left | 30lb | 13.6kg | 13 | 330/0.23 240/0.28 180/0.31 | 310/10 270/15 220/20 |
| ATH4500 | 4500 | 5.7:1 | Right/Left | 30lb | 13.6kg | 13 | 390/0.25 290/0.28 215/0.33 | 390/15 320/20 250/30 |
| ATH4500HS | 4500 | 7.0:1 | Right/Left | 30lb | 13.6kg | 13 | 390/0.25 290/0.28 215/0.33 | 390/15 320/20 250/30 |
| ATH5500 | 5500 | 5.2:1 | Right/Left | 40lb | 18.1kg | 13 | 390/0.28 300/0.33 210/0.36 | 500/20 380/30 335/40 |
| ATH6500 | 6500 | 5.2:1 | Right/Left | 40lb | 18.1kg | 13 | 355/0.33 315/0.36 185/0.38 | 485/30 410/40 335/50 |
| ATH6500HS | 6500 | 6.2:1 | Right/Left | 40lb | 18.1kg | 13 | 355/0.33 315/0.36 185/0.38 | 485/30 410/40 335/50 |
| ATH7500 | 7500 | 4.7:1 | Right/Left | 50lb | 22.6kg | 13 | 450/0.36 300/0.38 200/0.46 | 530/40 440/50 400/65 |
| ATH8500 | 8500 | 4.7:1 | Right/Left | 50lb | 22.6kg | 13 | 415/0.46 280/0.56 240/0.61 | 730/40 600/50 555/65 |
| ATH8500HS | 8500 | 5.3:1 | Right/Left | 50lb | 22.6kg | 13 | 415/0.46 280/0.56 240/0.61 | 730/40 600/50 555/65 |
| ATH10500 | 10500 | 4.2:1 | Right/Left | 60lb | 27.2kg | 13 | 395/0.56 330/0.61 230/0.71 | 845/50 780/65 540/80 |
